A split phase inverter is a kind of power electronic equipment, which is mainly used to convert DC (direct current) power supply to AC (alternating current) power and realize the regulation of output voltage and frequency.
Compared with traditional inverters, split phase inverters use time-sharing control technology, which realizes the output of alternating current through transistor staggered switching.
1. What is a split phase inverter
Many people often ask how many types of inverters there are. There are three types of solar inverters. They are single-phase, three-phase and split phase solar inverters. The working principle of an inverter is to convert DC to AC output.
Single phase inverter means that the voltage converted from direct current to alternating current is single-phase, that is, AC 220V. And the three phase inverter means that the voltage that converts DC to AC is three-phase, that is, AC 380V, a three-phase power supply.
It consists of three alternating potentials with the same frequency, equal amplitude and a phase difference of 120°, which can carry three-phase loads. In general, the inverter will only output one voltage. But in some countries, appliances have two input voltages, such as 110V/220V.
In this case, if a solar power system is used, a solar inverter that can output both 110V and 220V voltages is required. We call this type of inverter that can output two voltages a split phase inverter. Split phase inverters are suitable for residential and light commercial applications.
2. How split phase inverters work
Split phase inverter is a high-performance inverter that is mainly composed of phase shift control and full bridge topology. It works by dividing the input voltage into two or more phases, and then controlling the on/off of each phase converter by controlling the delay time of the preamble and hysteresis converters, so as to realize the regulation of the output voltage.
A split phase inverter consists of two sets of transistors, each of which switches half a cycle apart in switching time, alternating to form an alternating current output.
When the output voltage is higher than the rated value, the controller adjusts the switching time of the transistor to achieve stable regulation of the output voltage. The split phase inverter also has the function of grid connection, which can realize interconnection with the power grid.
Compared with traditional 2kw inverter, the output voltage of split phase inverters has the characteristics of high precision, high efficiency and high power density, so it is widely used in power electronics, industrial automation, new energy and other fields.
3. What are the advantages of split phase inverters
- High efficiency
The split phase inverter can achieve high-efficiency power conversion, thereby reducing energy loss and improving the overall efficiency of the system.
- Highly controllable
The split phase inverter mode of operation allows for high precision and high stability regulation and control of the output voltage, which can meet a variety of application scenarios with different needs.
- High power density
Split phase inverters can be miniaturized while maintaining high efficiency and stability, enabling systems to achieve more power efficiency in increasingly compact spaces.
4. Application areas of split phase inverters
Due to its advantages in output voltage stability, control performance, and interconnection, split phase inverters have a wide range of application scenarios.
It is usually used in 3000w inverter air conditioning, motor drive, UPS power supply, solar power generation and other fields. Split phase inverters can also be applied to the fast charging system of electric vehicles.
- Electric vehicles
Split phase inverters enable efficient energy conversion in electric vehicles, enabling high-precision power transfer between the on-board battery and the motor, thereby improving the overall performance and range of the vehicle.
- Solar power generation
Split phase inverters can provide efficient and reliable power conversion for solar energy systems, reduce system energy loss, and improve the performance and reliability of solar energy systems.
- Wind power generation
Split phase inverters can provide efficient and reliable power conversion functions for wind power generation systems, realize the full utilization of wind energy and reduce the energy loss of the system.
In summary, split phase inverter is a high-performance form of inverter, which has the advantages of high efficiency, high controllability, high power density, etc., and is widely used in power electronics, industrial automation, new energy and other fields, and has broad market development prospects.
5. Difference between a split phase inverter and a traditional inverter
Traditional inverters use DSP modulation technology that directly samples voltage and current, and the control circuit is complex and the measurement accuracy is limited.
The split phase inverter adopts time-sharing control technology, which is simpler and more efficient, the output voltage has higher accuracy and stability, and the waveform is more complete.
● Single-phase inverter vs split phase inverter
- Single-phase inverter
A single-phase inverter is a device that converts direct current into alternating current and is suitable for low-power applications. Since the waveform of the conversion current is not a sine wave, it generates large harmonics, so it is suitable for low-power applications such as small home appliances, office equipment, personal computers, and electronic devices.
In solar panel power generation systems, single-phase inverters are often used to convert the direct current generated by the panels into domestic alternating current and as part of a home's stand-alone power supply. In addition, single-phase inverters are also widely used in power supply, UPS systems, emergency power supply and other fields.
- Split phase inverter
A split phase inverter is a device that converts direct current into alternating current and is suitable for medium and high power fields. The conversion current waveform of the split phase inverter is closer to the sine wave and produces less harmonics, so it is suitable for medium and high power equipment.
Such as inverter air conditioners, servo motors, industrial electronic equipment, photovoltaic power stations, etc. In solar panel power generation systems, split phase inverters are usually used in medium and high power solar power generation systems, which are able to convert the direct current generated by high efficiency solar panels into domestic or industrial electricity.
In addition, split phase inverters can also be applied to on-board power equipment, avionics and other fields. To sum up, single-phase inverters and split phase inverters are different in terms of power range, application field, conversion current waveform, etc. Choosing the right type of inverter depends on the required power range and usage scenario.
6. Conclusion
With its characteristics of high precision, high stability, high reliability and high efficiency, split phase inverter has become the representative of a new generation of inverters. At the same time, it also has the advantages of grid connection and rapid response, which can better meet the high-quality needs of users for electric energy.
