TYCORUN PRODUCT PARAMETER
Tycorun 2400W Lithium Battery Storage All In One LiFePO4 Home Solar Power System Technology Parameter Sheet |
|
Model |
TC-SHS-2400 |
Battery rated voltage |
25.6VDC |
Battery Type |
Lifepo4 |
Battery Capacity |
100Ah |
Inverter |
|
Rated power |
1500W |
Input voltage range |
145-275VAC |
Input frequency |
45-65Hz |
Output voltage |
220VAC |
Output frequency |
50/60Hz |
Output wave |
Pure Sine Wave |
Specification of built-in battery |
1*100AH/25.6V |
Charge current |
10A |
MPPT Solar input |
|
MPPT Voltage Range |
30V-150VDC |
PV Power |
1200W |
Rated charge current |
50A(Max) |
MPPT efficiency |
≥99% |
Floating charge voltage |
28.8VDC |
DC output |
|
Low voltage recovery voltage |
26.8VDC |
Low voltage protection voltage |
22.8VDC |
5VDC USB output |
2units/MAX 2A |
12VDC output ports |
2units/MAX 2A |
Heat dissipation/Cooling |
Temperature control by intelligent exhaust fan |
Operating ambient temperature |
-20 - +50℃ |
Storage ambient temperature |
-25 - +55℃ |
Operating/Storage ambient |
0-90% No condensation |
External size:W*D*H(mm) |
575*326*600 |
Package size:W*D*H(mm) |
675*427*776 |
Weight (kg) |
54 |
INTERIOR STRUCTURE
PRODUCT ADVANTAGE
SUPER SAFETY TEST
Passed the below abuse and safety test-short-circuit, dropping, nail penetration, impact, crush, thermal shock, over-charge,over-discharge: no fire, no explosion with stable chemical structure.
